Product Specifications:
This solid carbide ball nose end mill is engineered for 3D profiling, contouring, and finishing operations on materials up to HRC 45. The TiAlN coating (dark grey) provides excellent heat resistance (up to 800°C) and high hardness, enabling high-speed machining of carbon steel, alloy steel, stainless steel, and cast iron. The ultra‑fine 0.5μm grain substrate ensures sharp cutting edges and superior wear resistance.
The 10mm ball nose (R5) design allows smooth step‑over finishing on curved surfaces, ideal for mold cavities, die components, aerospace parts, and general engraving. With an overall length of 72mm and flute length of 20mm, this end mill is well‑suited for both roughing and finishing passes on CNC machining centers. The optimized 2‑flute geometry provides excellent chip clearance.
Typical applications include injection mold cores, automotive stamping dies, turbine blades, and decorative engraving. Custom diameters (1‑20mm), lengths, and alternative coatings (AlTiN, DLC) are available for OEM orders. For precise profiling and high‑quality surface finish in HRC45 materials, this TiAlN‑coated ball nose end mill delivers consistent performance and long tool life.
📏 Standard sizes are listed on our size chart page. Need a non‑standard diameter, length, or shank? Custom sizes are also available – just tell us your requirements.
